*Series 3* CO2 Maximizer

**CURRENTLY SOLD MODEL**

Saves 50% of the regular C02 consumption
Extends life and ease of cleaning of mug frosters, coffee machines, drive thru window and all the equipment in the store (with optional snap back hose)

19L stainless steel tank, 115v 60Hz 4 Amp (within 5' of a 15A receptacle)
Noise only 49 dB

ROI less than 18 months (based on average 88K +) Includes CO2 cost, delivery and leases.

Warranty 1 year - 100% parts and labor on site. 2 years on parts on reciept of failed part.
Comes complete with tubing, pre-assembled single or dual outlet manifold, fittings to enable installation at a simplified level

Oil-less (medical, food grade, air)

Dimensions 12” (300mm) wide x 9” (228mm) deep x 32 1/8” (816mm) high
Floor mount or wall hung. Will fit under a counter.

Installation Approximately 1 ½ to 2 ½ hours with 3-7 minutes down time for soda fountains

Ship weight 38 lbs
Shipping dimensions 37”  x 14”  x 14”

Options:

• 50 snap back hose with gun
• Extra store outlets for hose/ gun
• CO2 low pressure alarm
• Timed Drain (recommended on stores 1.5 Million + in sales)

Service Instructions:
Replacement of Inlet Filter: PDF Instructions to Replace Inlet Filter
Replacement of Water Trap Element: PDF Instructions to Replace Water Trap Element
